小型數控XK7126數控銑
立即咨詢
聯系熱線 15863228629
| Specifications | Units | XK7126 | XH7126 |
| 工作臺尺寸Table size | mm | 800x260 | 800x260 |
| X軸行程X axis travel | mm | 450 | 450 |
| Y軸行程Y axis travel | mm | 320 | 320 |
| Z軸行程Z axis travel | mm | 400 | 400 |
| 工作臺更大承重Max. worktable load | kg | 200 | 200 |
| T型槽（數量-寬度-間隙） | 3-14x80 | 3-14x80 | |
| T slot(number-width-pitch) | |||
| 主軸轉速M(fèi)ax. spindle speed | rpm | 6000 | 6000 |
| 主軸錐度Spindle taper | mm | BT40 | BT40 |
| 主電機功率Main motor power | kw | 3.7 | 3.7 |
| X/Y/Z軸快移速度 | m/min | 15/15/15 | 15/15/15 |
| X/Y/Z rapid traverse speed | |||
| 切削進給速度Cutting feed speed | mm/min | 1-6000 | 1-6000 |
| 導軌形式Guide rail type | Linear rail | Linear rail | |
| 主軸中心到立柱表面距離 | mm | 360 | 360 |
| Distance from spindle axis to column surface | |||
| 主軸端部到工作臺表面距離 | mm | 90-520 | 90-520 |
| Distance between spindle nose and worktable surface | |||
| 定位精度Positioning accuracy | mm | ±0.015 | ±0.015 |
| 重復定位精度Repeat positioning accuracy | mm | ±0.0075 | ±0.0075 |
| 刀庫Tool magazine | - | 12 Armless/(Optional: Arm 16 ) | |
| 刀具更大直徑Max. tool diameter | mm | - | 130 |
| 刀具更大重量Max.tool weight | kg | - | 8 |
| 機床重量Machine weight | kg | 2100 | 2400 |
| 外形尺寸Overall dimension | mm | 2200x1900x2200 | 2200x1900x2200 |
